The 9000LB Heavy Duty Shipping Container Axle with Ratchet Strap is designed to simplify the movement of up to 40ft shipping containers. This container moving tool ensures reliable performance for transporting heavy loads with ease. Featuring a robust ratchet strap system, it provides secure handling during operations.

Specification

Type 1:

Product Name: 6-Lug Container Wheel with Handle

Load Capacity: about 9000lbs / 4082.4kg

Product Color: Black

Product Material: 1045 Cold-Rolled Steel

6-lug Hub Dimensions: 30 x 28 x 10.4cm / 11.8 x 11.02 x 4.09 in (L x W x H)

The diameter of the circle formed by the 6 lugs is 13.9 cm / 5.5 in

Fixing screw size: 9.5 x 6.2cm / 3.74 x 2.44in

Screw diameter 21mm / 0.8 in

Suitable tire center bore diameter: about 6.5cm / 2.5 in

Product weight: about 30kg/66.1lbs

Type 2:

Product name: 8-lug container wheel with handle

Load capacity: 9000lbs / 4082.4kg

Product color: Black

Product material: 1045 cold-rolled steel

Product dimensions: 30 x 28 x 10.4cm / 11.8 x 11.02 x 4.09 in (L x W x H)

The diameter of the circle formed by the 8 lugs is 16.5 cm / 6.5 in

Fixing screw size: 9.5 x 6.2cm / 3.74 x 2.44in

Screw diameter 21mm / 0.8 in

Suitable tire center hole diameter: 6.5cm / 2.5 in

Product weight: about 35kg/77.2lbs

Installation way:

1. Insert the lugs on the trailer axle idler wheel hub into the lug tire hub and tighten the screws.

2. Insert the container wheel hub lug adapter (fixing bolt) into the container loading and unloading fixing hole pocket and into the bottom interface, and secure it with screws.

Packing List:

Shipping Container Wheels x2

Installation bolts x2

Ratchet strap x2

Ratchet buckle x2

Instruction manual x1
